Video Streaming
- 1. Video Streaming Ing. MarcoBertini - Ing. Gianpaolo D’Amico Università degli Studi di Firenze Via S. Marta 3 - 50139 - Firenze - Italy Tel.: +39-055-4796540 Fax: +39-055-4796363 E-mail: bertini@dsi.unifi.it Web: http://viplab.dsi.unifi.it/
- 2. Program: Module 1: What is streaming? Video and Internet Transmissions protocols Module 2: Shooting, Capturing, Editing, Serving, Playing; Technologies; Resources and case studies;
- 3. What is streaming? Streamingconcept Streaming was first introduced by RealNetworks some years ago. It consists of a technique for making video, audio and other multimedia available quickly via the Internet. The advantage of streaming is that it can enable easier access to multimedia resources. Another possibility is the integration of video and audio with other web-based applications, such as chat and other real-time collaboration tools.
- 4. What is streaming? Streamingvs. downloading What Is The Difference Between Downloading and Streaming? When you download a video, you have to copy the entire file to your hard disk before you can play it.
- 5. What is streaming? Streamingvs. downloading 2 What Is The Difference Between Downloading and Streaming? When the video is streamed, there is a small wait as the stream 'buffers' but there is no need to save the file. Streaming is the act of sending media files (audio and/or video) over the Internet from one computer to another computer so that the media plays as it is being delivered.
- 6. What is streaming? Streamingcategories Live When an event is delivered via the Internet at the same time it is happening. Example: live concerts, live radio, videoconferences. On Demand When the event is recorded on a digital support and saved in a server and after made accessible by Internet users. Example: video clips, movies trailers.
- 7. Recap of StreamingMedia Why using this technology? o To overcome limitations of WWW. What is streaming media? Streaming is not o Download all before playback is able o Media created with software like Macromedia Flash. Major streaming formats o Microsoft Windows Media o Real Networks o Apple Quicktime
- 8. Streaming Video • Progressive streaming • Download a compressed video file to your hard drive via HTTP over the Internet • Use standard web server • Quality is better than real-time streaming • Real-time streaming • Don’t need to download the entire video before playing • Require a special streaming server
- 9. Why Streaming Media? No waiting for complete downloads. Streamed files are not written to disk. Presentation of live events is possible. Enhance static web pages.
- 10. Video and Internet Possibleapplications Internet radio Internet tv E-commerce website Training video Video conference Remote presence Classroom setting Realtime collaboration Audio + video + animation = multimedia RIA Rich mouse + keyboard + user = interaction Internet Applications
- 11. Video and Internet Howdoes streaming work? The streaming media development process
- 12. Video and Internet Howdoes streaming work? How Is Streaming Different From Broadcasting? Delivery of broadcast TV: - Broadcast “blankets” the area with its signal (persistent); - TVs are standardized by region. Every TV knows how to receive TV Broadcast; - Any TV can “reach up and grab” broadcast signal and pulls it down to set; - broadcast doesn’t reach every “air” is (line of sight); - TVs outside the broadcast line of sight can’t grab signal
- 13. Video and Internet Howdoes streaming work? How Is Streaming Different From Broadcasting? Delivery of streaming video: - server only sends signal out to computers which want it (signal is not persistent); - computer media players are not compatible with one other; - computer must request video stream. Media player must be compatible; - No physical barriers: stream can reach anywhere on the Internet; - Computers must meet minimum bandwidth requirements
- 14. Video and Internet Howdoes streaming work? Streaming media playback in theory
- 15. Web bandwidth Source: http://www.adobe.com/products/aftereffects/pdfs/ AdobeStr.pdf
- 16. Internet Media Streaming DSL Streaming client Media Server Internet 56K modem wireless Best-effort packet network Challenges • low bit-rate • compression • variable throughput • rate scalability • variable loss • error resiliency • variable delay • low latency
- 17. Transmissions protocols In generalthere are two methods to deliver a media file on the Web: by a normal web server with the HTTP protocol, or by a dedicated server (streaming server) with the RTSP protocol (Real Time Streaming Protocol) or another similar streaming protocol. HTTP protocol based on TCP/IP, it was created to deliver text and images files, not streaming media files. The normal process of an HTTP request consists of the communication opening between the client (the browser) and the web server, the file request, the file delivering and the closing of the connection. There’s no space to “play” a file. RTP protocol Layered on top of UDP, so there’s no error handling or reliability. One-to-one or one-to- many (original goal) transmission. Includes payload type identification, sequence numbering and time stamping (SMPTE timecode). RTSP protocol based on TCP for communication and usually layered on top of RTP, it is dedicated to streaming. By this protocol you can control the file time "duration“, which can be played with different speed, can be controlled by the server, can be stopped and played again, and its playing can be changed at runtime depending on different parameters.
- 18. RTP is one way stream, RTSP enables control of streaming media (two way, like HTTP)
- 19. Transmissions protocols RTSP (Real Time Streaming Protocol) high priority on continuous streaming rather than on absolute document security RTMP (Real Time Messaging Protocol) Is a proprietary protocol developed by Adobe Systems used with Macromedia Flash Media Server to stream to the Adobe Flash Player client. MMS (Microsoft Media Server). This server cluster is able to handle up to 30,000 20k streams concurrently
- 20. Transmissions protocols - TCP -UDP - RTSP (RealTime Streaming Protocol) Real Networks QuickTime Windows Media (default) - MMS (Microsoft Media Server) Microsoft MMSU/MMST MSBD (Media Stream Broadcast Distribution) - RTMP (Real Time Messaging protocol ) Macromedia Flash - HTTP slower transparent to firewall lack of streaming functionalities
- 21. RTSP / RTP RTSP Control Connection (usually TCP) SETUP PLAY DESCRIBE request request request SETUP PLAY DESCRIBE reply reply reply RTP Data Stream (UDP) Media Packet Media Packet Media Packet Media Packet Report Report
- 22.
- 23. Multiple Bit RateEncoding Combine several different streams into a single file The appropriate bit rate stream is automatically selected
- 24. The development process Contentplanning 1 - Narrative like conventional film and television, video streaming is all about telling stories. - What is special about streaming? unlike conventional film, some media are often displayed and used with other web resources such as web pages, animation, and messaging, which enrich the user experience. In addition, in digital media there is less emphasis on sequential narrative - Scripts and storyboards What you have to say (script) and what do you want to show (storyboard)
- 25. The development process Contentplanning 2 - Shooting video for streaming How you actually shoot your subject depends on the subject and how you intend to use the video. Some tips to consider for a single lecturer for example: • Composition • Timing • Movement • User-orientation
- 26. The development process Contentplanning 3 - Preparing for filming Live broadcasts Location Shooting the subject close up Shooting for streaming keep it simple ! Simple background Tips for shooting even lighting not too much action or camera movement The presenter
- 27. The development process Theequipment Video camera Tripod Microphone Lights Capture card Computer Encoding software Streaming server Shaky camera: troubles for the encoder
- 28. The development process Capturingthe video What computer hardware will you need? Capturing from digital Capturing from analogue What software will I need?
- 29. Capturing Video Get all data to the computer digitally. Use highest possible quality settings. 25 fps for video and 16-bit for audio is suitable.
- 30. Capturing Video tips Resize the frame at 4:3 ratio when digitizing it Keep width and height multiple of 16, for the codec Eventually crop some pixels before resizing, to keep aspect ratio Deinterlace
- 31. The development process Alternativesto filming - Existing video material resources - Audio only - Screen capture software - Macromedia Flash
- 32. The development process Editing - Editingtips for streaming Save an original copy File formats deinterlace: it’s frame not field ! Crop the film multiple of 16x16 Reduce the picture size. Do not use too many special effects titles outside of video frame Keep the clips short Avoid background sounds such as music or talking Enhance the audio signal
- 33. The development process Encoders and players Encoding, two main questions: What media player will be used (e.g. Windows Media Player, RealOne media player, Flash)? What Internet connection speed will be available? There is usually the option of delivering different quality of streams to users with different connection speeds. Use the multiple bit rate encoding features of the streaming encoder
- 34. Edit AdobePremiere –tool for digital video editing Putclips together Make transitions Add effects Adding sound Composea video production for streaming
- 35. Some Advices : Don’t add too much effects (transitions, dissolves, 3D-text etc.) Sometimes video sequences could be replaced with slow-motion or still images Make titles large and simple Audio
- 36. Integration With SMIL SMIL let you choreograph rich media presentations SMIL is to streaming servers what HTML is to web servers You bring together your presentations using SMIL RealNetworks supports SMIL in its player Also IE >= 5.5 supports SMIL in HTML files
- 37.
- 38. Technologies Real Networks Apple Quicktime RealPlayer Quicktime Player RealProducer QuickTimeStreaming RealServer Server Helix OpenSource Darwin OpenSource Microsoft (WMT) Macromedia Flash WindowsMediaPlayer Flash Player WindowsMediaEncoder Communication Server Mx WindowsMediaServer
- 39. Macromedia/Adobe uses On2 VP6 or Sorenson codec for Flash video (FLV) Flash video does also real streaming Note: Google Video/YouTube use Flash video (and also all the other video sharing services: the player is embedded in the web page)
- 40. Streaming Server Touse real time streaming you must use specific streaming servers. To upload data to a streaming server, you must save the data in a data type format that the server is able to stream. For example, SMIL -file.
- 41. Streaming Server… Microsoft, Real networks and Apple also provide streaming servers. Streamingservers for real time streaming do not use the same protocols as an ordinary HTTP server.
- 42. Pros of StreamingServers Can broadcast and multicast (one stream to many users) Doesn’t leave a copy of the users hard drive (if the user does not use straming capture programs…) Bandwidth usage can adjust to conditions
- 43. Cons of StreamingServers The data that get lost in the transmission get lost forever Playback or data can be delayed or disrupted because the data rate gets bigger than the bandwidth Firewalls may not allow streaming files pass
- 44. Streaming Media Today Is used for movie trailers Live broadcasting
- 45. The Future Iftheuser has a fast connection, streaming media is a practical way for broadcasting multimedia The future for streaming is bright Entire movies can probably be streamed The technology will be improved Distance courses by streaming media
